January 9, 2024
We recently acquired dozens of Used Macroair HVLS fans, and are pulling them out of their current location in Kentucky by Mid-February. Lock-in our the best price and save on freight when you order direct from the jobsite! Request a quote today and get started before the fans disappear!
| Detailed Specifications |
| Specification | 16' Unit | 18' Unit | 20' Unit | 24' Unit |
| Airfoil |
| Airfoil Style | 7.375" Extruded Anodized Aluminum Airfoil |
| # Of Airfoils | 6 |
| Performance |
| Max Speed | 84 RPM | 70 RPM | 62 RPM |
| Recommended Spacing | 85 ft | 90 ft | 100 ft | 110 ft |
| Max Affected Area | 12,000 sqft | 14,000 sqft | 18,000 sqft | 20,000 sqft |
| Sound level dBA @ Max Speed | 58 | 61 |
| Hanging Requirements |
| Hanging Weight | 202 lbs | 208 lbs | 217 lbs | 270 lbs |
| Max Torque | 40 ft-lb | 58 ft-lb | 88 ft-lb | 126 ft-lb |
| Max Thrust In Reverse | 15 lbs | 21 lbs | 31 lbs | 44 lbs |
| Motor & Drive Train |
| Motor Type | AC Induction Motor w/ Sealed 2-Stage Helical Gear Box |
| Equivalent Horsepower | 1.0 HP | 1.5 HP | 2.0 HP |
| Power Requirements |
| Power Source | Wired for 3Ø 480 VAC @ 50/60 Hz |
| Max Amp Draw | 4.3A |
| Installation |
| Mounting Hardware | Universal Mount Hardware |
| Extensions | Optional Extensions Available From MFG (Not Included) |
| Ratings & Compliance |
| Fire & Sprinkler | NFPA Compliant |
| Wash Down Duty Rating | Fan Unit IP55 Rated, Controller Control Panel Not Rated |
| Certifications | UL507 |
Save 40% Off New: Dozens of HVLS Fans Are Inbound Soon!
Keep Your Warehouse Cool And Comfortable Year-Round Without The Expensive Startup & Upkeep costs of HVAC! HVLS (High-Volume, Low-Speed) Fans circulate air in your facility, gently pushing hot air down from the ceiling during the winter, and keeping your facility ventilated and more comfortable during the summer.
We recently acquired dozens of Used Macroair HVLS fans, and are pulling them out of their current location in Kentucky by Mid-February. Lock-in our the best price and save on freight when you order direct from the jobsite! Request a quote today and get started before the fans disappear!
Request a Quote Today!
| Inbound Products | Inventory Updated 1/9/24 -- Call For Latest Updates! |
| Product | Quantity | Diameter | New Price | ASI Price (Save 40%!) |
| Used Macroair HVLS Fans | 42 | 16' | $6,575 ea. | $3,945 ea. |
| Used Macroair HVLS Fans | 12 | 18' | $6,600 ea. | $3,960 ea. |
| Used Macroair HVLS Fans | 12 | 20' | $6,650 ea. | $3,990 ea. |
| Used Macroair HVLS Fans | 7 | 24' | $6,700 ea. | $4,020 ea. |
