Stretch Wrapper

TECHNOPLAT CS Manufacturer Brochure

Performance Features:

  • The remote control comes standard with the Technoplat and can control up to 4 units.
  • The cut, clamp and spreading system (CS) ensures a perfect adherence of the final round of film on the wrapped product.
  • Ensure a perfect adherence of the film to the load for better containment with the cut, clamp and welding system (CW).
  • The high performance 7-inch color touch screen with icons specifically designed and created by Robopac for our stretch wrap turntable machines has led to the implementation of the MULTILEVEL CONTROL function.
  • Powered stretch system controlled by two motors. Stretch ratio adjustable from panel board from 150-400%.
  • R-Connect, standard for this turntable stretch wrapping machine, provides usage and performance data via the cloud, enabling you to meet Industry 4.0 demands by putting performance monitoring & optimization at your fingertips.

New TechnoPlat 708 CS Stretch Wrapper Machines

As Low As:

Call or Request Quote

Request a Quote
  • TECHNOPLAT 708 CS Semi-Automatic Stretch Wrapper by RoboPac
  • Multi-Level Variable Film Pre Stretch 100%-400%
  • Power Variable Stretch Film Delivery
  • Cut & Swipe Film Tail System
  • Reduce your film usage by 30% – 55%
  • Supports R-Connect
  • Capacity:4,400 lbs.
  • Stretch wrapper wrap height: 86"or110"
  • Remote included
  • Clamp, cutting, and spreading unit
  • Color touch screen
  • Ships From Manufacturer

SKU Description BrandCapacityElectrical Input RequirementsFilm Delivery SystemFilm Pre-StretchFilm Tail SystemIncludes R-Connect?Stretch Wrapper Wrap HeightTurntableWeight Item Price Qty.
TECHNOPLAT86
TechnoPlat 708 CS Semi-Automatic Stretch Wrapper - 86"
RoboPac4,400 lbs.120V, 1Ø, 12A, 60HzPower Variable StretchMulti-Level Variable 100%-400%Cut & Swipe SystemNo86"65" Diameter1,600 lbs.
Please request a quote
Qty:
TECHNOPLAT110
TechnoPlat 708 CS Semi-Automatic Stretch Wrapper w/ R-Connect - 110"
RoboPac4,400 lbs.120V, 1Ø, 12A, 60HzPower Variable StretchMulti-Level Variable 100%-400%Cut & Swipe SystemYes110"65" Diameter1,600 lbs.
Please request a quote
Qty:
ROBOINSTALL
RoboPac Stretch Wrapper Installation & Training Service
Please request a quote
Qty:

The Technoplat 708 CS (Clamp, cutting and sealing unit) semi-automatic turntable stretch wrapping machine cuts and attaches the film tail to the load at the end of the wrap cycle for superior load containment. The Technoplat 708 CS semi-automatic shrink wrapper saves 2 minutes of labor per load by keeping the operator on the fork truck. For the average customer, this translates to labor savings of $29,000 over 5 years and $60,000 over the life of the machine!

Our Remote-Control start allows the fork truck operator to start the wrap cycle while staying on the fork truck. This allows them to leave the current load to pick up and stage another load which improves productivity.

R-Connect now included as standard feature (includes 36-month initial cellular data plan).

American Surplus is committed to deliver our customers premium semi-automatic stretch wrapper machines. Therefore, we’ve partnered with ROBOPAC to provide the quality products our customers deserve. For more information or to request a quote call one of our sales associates today!


Specification TechnoPlat 708 CS TechnoPlat 708 CS w/ R-Connect
R-Connect No 3 Year Plan of Remote Machine Monitoring and Film Consumption Tracking Included
Performance
Production Speed Up to 40 LPH
Turntable Speed 5-15 RPM
Turntable Drive 1 HP vAC
Automation Device
Film Tail Treatment Cut & Swipe System
Remote Control Remote Control
Pull Cord/Lanyard Start System Standard
Load Handling
Turntable Size 65" Diameter
Maximum Load Height 86" 110"
Maximum Load Weight 4,400 lbs.
Film Delivery System Power Variable Stretch
Standard Pre-Stretch Multi-Level Variable 150%-400%
Force-to-Load Variable Electronic 0%-100%
Core Compensation Load Cell
Standard Film Width 20"
Load Height Detection Infrared Photocell
Machine Dimensions
Approx. Shipping Weight 1,600 lbs.
Approx. Shipping Size 126"L x 89"W x 30"H
Service Requirements
Electric 120V, 1Ø, 12A, 60Hz
NEMA 13 Enclosure Standard
Required Air Supply 87 PSI
UL, cUL, & CE Compliant Yes
Warranty 5 Year
